| Physical Properties |
Metric |
English |
Comments |
| Density |
1.17 g/cc |
0.0423 lb/in³ |
| Water Absorption |
1.30 % |
1.30 % |
| Linear Mold Shrinkage |
0.00400 cm/cm |
0.00400 in/in |
| |
| Mechanical Properties |
Metric |
English |
Comments |
| Hardness, Rockwell R |
40 |
40 |
| Tensile Strength, Ultimate |
33.8 MPa |
4900 psi |
| Tensile Strength, Yield |
25.5 MPa |
3700 psi |
| Elongation at Break |
50.0 % |
50.0 % |
| Flexural Modulus |
1.103 GPa |
160.0 ksi |
| Flexural Yield Strength |
33.1 MPa |
4800 psi |
| Izod Impact, Notched |
3.31 J/cm |
6.20 ft-lb/in |
|
1.07 J/cm
@Temperature -40.0 °C |
2.00 ft-lb/in
@Temperature -40.0 °F |
| |
| Electrical Properties |
Metric |
English |
Comments |
| Electrical Resistivity |
1.00e+13 - 1.00e+15 ohm-cm |
1.00e+13 - 1.00e+15 ohm-cm |
| Dielectric Constant |
3.55
@Frequency 1e+6 Hz |
3.55
@Frequency 1e+6 Hz |
| Dielectric Strength |
15.25 kV/mm |
387.4 kV/in |
| Dissipation Factor |
0.0800
@Frequency 1e+6 Hz |
0.0800
@Frequency 1e+6 Hz |
| |
| Thermal Properties |
Metric |
English |
Comments |
| CTE, linear |
11.0 - 17.0 µm/m-°C
@Temperature 20.0 °C |
6.11 - 9.44 µin/in-°F
@Temperature 68.0 °F |
| Specific Heat Capacity |
1.465 J/g-°C |
0.3501 BTU/lb-°F |
| Thermal Conductivity |
0.250 W/m-K |
1.74 BTU-in/hr-ft²-°F |
| Deflection Temperature at 0.46 MPa (66 psi) |
77.0 °C |
171 °F |
| Deflection Temperature at 1.8 MPa (264 psi) |
64.0 °C |
147 °F |
| Vicat Softening Point |
96.0 °C |
205 °F |
| |
| Optical Properties |
Metric |
English |
Comments |
| Refractive Index |
1.475 |
1.475 |
| Haze |
<= 8.50 %
@Thickness 1.52 mm |
<= 8.50 %
@Thickness 0.0598 in |
| Transmission, Visible |
>= 90.0 %
@Thickness 1.52 mm |
>= 90.0 %
@Thickness 0.0598 in |
